Here Is The Latest Creation From Red Barn Customs. One Of Our Best Customers Hauled His Rolling Chassis 8 Hours One Way All The Way Up To Us From South Indiana. His Name Is John Moore From Columbus.  We Basically Took This 1990 Chevy Extended Cab Body Completely Off Of Its Stock Frame. Cut Ever Non Usable Part Off The Frame. We Sand Blasted The Bare Frame To Get All Of The Under Coating And Rust Off Before We Started The Intense Frame Build. We Took The Stock Frame And Welded Up Side Down On Our Frame Jig, Straighten The Main Frame Rails With In 1/16". All Of The Stock Cross Members We Cut Out, Rivots Removed And New 2" DOM .120 Wall Tubing Was Installed Along With A Heavy Duty .250 Wall 2" x 4" Rectangle Tube. This Was Welded From Side To Side And Tied In With A "X" Brace. The Lower Sub Frame Is Also Made Out Of 2" DOM .120 Wall Tubing. Up Front Where The Upper "A" Arm Brackets Were Welded From The Factory We Cut The Frame Out And Installed Some New Steel For A Super Clean Look. We Made All Of The Shock & 4 Link Brackets In House And They Are From 3/8" Plate. This Frame Also Got The New "Big Shocks.Com"-- 16" Travel W/External Resivoir & 1" Stainless Steel Shafts. This Truck Has Custom Made Lower Link Bar Brackets For John Moore. The Drivers Side Has His 1st Name And The Passengers Side Has His Last Name. We Also Built A Custom Wrap Around Cross Member Mount For His Divorsed NP 200 Transfer Case. John Plans On Adding An SCS Drop Box In The Future As We All Know How The Build Evolves. This Truck Was Built For A 598 Big Block Chevy, Turbo 400, NP 205 & NP 200 To Make The Gearing Almost 4 To 1. We Mocked It Up With Gang Green's 18.4 x 26 R2 "Rice & Cains" That Stand 58" Tall. The Rear Axle Housing Got Some Attention Too, We Staightened It And Bored Out The Spindles To Accept Ouverson's 2" 47 Spline Violator Shafts. This Truck Build Was Very Intense And Took Quite "ALOT" Of Hours To Build. This Is A "ONE OF A KIND BUILD" That All Of Us Here At Red Barn Customs Put Alot Of Pride In Building This For John Moore And His Family. John Has Alot Of Work Ahead Of Him This Year To Finish The Rolling Chassis That We Helped Started For Him. If You See This Truck Any Where At A Mud Bog Or Getting Pulled Down The Road On Trailer Please Tell Him How Much You Like It. We Really Love To Build Trucks Like This Because All Of Us Here Live For This Stuff...........Thank You For Letting Us Build This For You John.

For Detailed Pics Please Click The Photo Bucket Link There Are A Bunch

http://s480.photobucket.com/albums/rr166/Red_Barn_Customs/John%20Moores%20Truck%20Build%202010/?start=all

Support Your Local Michigan Business We Sell Everything Related To 2.5 Ton And 5 Ton Rockwell Axles. If You Don't See It On Any Of These Pages We Can Get It For You. We Deal With Many Companies To Help You Get All Of Your Rockwell Axle Parts At One Stop.

Custom Rockwell Rims For 2.5 Ton, 5 Ton, And Planetary Axles Please Call For Details....(Use Rockwell Rim Tab)

Rockwell Axle Take Outs, Rockwell Axle Shafts For Used Take Outs And New After Market (Use Rockwell Parts 1 & 2 Tabs)

Rockwell Pinion Brakes, Rockwell Wheel (Disc) Brakes, Rockwell Hydralic Steering Kits, Rockwell Lift Blocks, Rockwell U-Bolts,  Every Rockwell Seal, Gasket, And Bearings, 5 Differant 2.5 Ton Rockwell Dust Boots. (Use Rockwell Parts 1 & 2 Tabs)

We Sell Coil Over Shocks (Big Shocks) & (King Off Road) (Use Rockwell Parts 3 Tab)

RBC Offer Custom CNC Plasma Table Service For Any Type Of Bracket, Plate, Or What Ever Your Looking For.

Please Call For Parts Or Tech Sevice. We Now Have A New Trucking Rates For Shipping Large Items Like Rockwell Axles And Rockwell Rims.

We Can Cut Special One Of A Kind Parts With Our Own CNC Plasma Table. Call For Pricing Quotes..........

IF YOU'RE LOOKING FOR A SPECIAL OR HARD TO FIND PART AND DON'T SEE IT HERE ON THE WEB SITE, PLEASE CALL ME @ 1-866-787-0629 LUKE. WE CAN GET JUST ABOUT ANYTHING YOU'RE LOOKING FOR OR WE CAN PROGRAM AND CUT IT ON OUR CNC PLASMA TABLE. THERE ARE TOO MANY PICS OF STUFF TO PUT UP......

2.5 Ton Axle Service:                   Straighten Steer Axle Housing Cut Off Both Sides Where King Pins Weld To Housing Tube $ 250.00

                                                  Shorten Steer Axle Housing 7" To Run 2 Short Side Axle Assemblies  $ 250.00    Plus Price Of Parts

                                                  Straighten Rear Axle Housing To Free Up Axle Binding $ 250.00

For More Additional Service Please Click The RBC Service Tab Or Call 1-866-787-0629 Toll Free

2.5 Ton Rockwell Axle Set-Take Out Set- 1 Steer & 1 Rear W/Drums-(As Is) They Are Right From Under The 6x6 Truck That They Were Made With. $1500.00

These Move Fast So We Are Always Getting More In All Of The Time.

2.5 Ton Rockwell Chunks $350.00

For All Other Parts Click "Rockwell Parts 1" Or "Rockwell Parts 2" Tabs

2.5 Ton Rockwell Deluxe Axle Set- 1 Steer & 1 Rear, W/U-Joint Axle Shafts, Completely Torn Down, Power Washed, Sand Blasted, Primed With 2 Part Epoxy Primer, Painted Gloss Black (Or Your Color Of Choice), Resealed With New Seals, New Paper Gaskets, New Boots (Your Choice Of 5 Styles To Choose From), 2 New Large Clamps, 2 New Small Clamps, Wheel Hub Bearings Cleaned & Packed WIth Grease, Grease Zerks Installed In All 4 Wheel Hubs, Rear Axle Hubs Flipped Outwards (So They Track With The Steer Axle). New Grade 8* Bolts Installed For The Spindles And The Chunk. $2500.00 For The Set, $1500.00 Steer Only, $1000.00 Rear Only

If you would like all new 24 RH studs and 24 RH Lugs add $200

RBC Can Install A Locker, Spool, Or Welded Carrier If You Buy Them From Us. We Can Install Weld On Blocks Or 4 Link Hangers. Please Call 1-866-787-0629 For Details

2.5 Ton Rockwell Axle Set-("Rock Crawler Specials")- 2 Steer Axles W/(4) U-Joint Axle Shafts, Both Lower Bowls Of The Axle Housings Have Been Shaved, And "MOHAWKED" W/ 3/8" Steel Plate, Welded Inside/Out. They Have Been Completely Torn Down, Power Washed, Sand Blasted, Primed With 2 Part Epoxy Primer, Painted Gloss Black (Or Your Color Of Choice), Resealed With New Seals, New Paper Gaskets, New Boots (Your Choice Of 5 Styles To Choose From), 4 New Large Clamps, 4 New Small Clamps, Wheel Hub Bearings Cleaned & Packed WIth Grease, Grease Zerks Installed In All 4 Wheel Hubs, All 4 Axle Hubs Flipped Inwards (So They Both Track Narrow With Each Other). New Grade 8* Bolts Installed For The Spindles And The Chunks. On The Steer Axle That Would Be Used For The Rear We Have The Center Section (Chunk) Flipped 180* So The Pinion Shaft Is Centered To Help Give You A Better Drive Line Angle. These Are Custom Built To Order Only. I Have 2 Housing Done And Need To Be Finished To Your Custom Order. These Will Sold As A Set Only.

$4000.00 For The Set

RBC Can Install A Locker, Spool, Or Welded Carrier If You Buy Them From Us. We Can Install Weld On Blocks Or 4 Link Hangers. Please Call 1-866-787-0629 For Details

5 Ton Rockwell Axle Set, (1 Steer Axle & 1 Rear Axle) 6.44: 1 Gear Ratios, With The Drum Brakes Cleanly Removed, The Rear Hubs Are Flipped Outwards, All Of The Bearings Have Been Cleaned &  Repacked, New Zipper Boots, U-Joint Axle Shafts    $2500.00

RBC Can Install A Locker, Spool, Or Welded Carrier If You Buy Them From Us. We Can Paint Them, Weld On Blocks Or 4 Link Hangers. Please Call For Details

I Have 2 Separate 5 Ton Rear Axles, Both are De-Braked, Bearings Cleaned And Repacked, Hubs Are Flipped Out. $1000.00 Each

5 Ton Chunks Availible, Rear Shafts, 3 Types Of Front Shafts (Burfield, Rezeppa, And U-Joint Styles. Please Call For Pricing. Also I Have A Line Availible Of High Performance After Market Shafts, Lockers, Spools. 1-866-787-0629 Luke
